Vicon - Tedders

VICON FANEX 464 - 524T - 524
Vicon offers 3 versions of compact tedders with low maintenance requirements and a working-width ranging from 4.6m to 5.2m. Maintenance-friendly features include 500mm rotor plates and an easy-to-maintain gearbox. All tedders can be adjusted centrally to move the tedder to the desired position for border tedding

ADVANTAGES:
Low maintenance CompactLine gearbox with only one grease nipple.
Compact tedders with low weight and power requirements.
Rotor plate dimension of 500mm.
Double bearings from pinion to crown wheel guarantee maximum longevity of the driveline.
Super-C tines with large spring coil diameter for added service life.
Easy setting of spreading angle through simple three-way adjustment of wheel height.

MODELS

FANEX 464
Working Width 4.60m
Rotors/Tines 4/5
Weight 492kg

FANEX 524
Working Width 5.20m
Rotors/Tines 4/6
Weight 520kg

FANEX 524T
Working Width 5.20m
Rotors/Tines 4/6

Weight 520kg

VICON FANEX 604 - 804
Vicon Fanex 604 and 804 are purpose-built for haymaking. Both models come with a strong package of features such as standard vibration dampers, strong V-shaped central unit and central adjustment for border tedding. They offer considerable operation capabilities with their combination of 6/8 rotors and 6.05/8.05m working width. The small rotors are specially designed for optimized performance while producing dry hay.

ADVANTAGES:
Low maintenance CompactLine gearbox with only one grease nipple.
Compact tedders with low weight and power requirements.
Standard fitted with vibration dampers and strong central unit.
HexaLink driveline on Fanex 804 ensures compact folding.
Rotor plate dimension of 500mm
Double bearings from pinion to crown wheel guarantee maximum longevity of the driveline.
Super-C tines with large spring coil diameter for added service life.
Easy setting of spreading angle through simple three-way adjustment of wheel height.

MODELS

FANEX 604
Working Width 6.05m
Rotors/Tines 6/5
Weight 677kg

FANEX 804
Working Width 8.05m
Rotors/Tines 8/5
Weight 950kg

VICON FANEX 554-684-764-904-1124

The Fanex 554, 684, 764 904 and 1124 are designed to perform perfectly in all crop conditions, with a minimum of non-productive maintenance required and with diminished transport dimensions.  Featuring a heavy-duty fully closed headstock this machine will fit perfectly into the operation of professional farmers, looking for a strong, effective, and versatile tedder.

These tedders are fitted with a high-performance driveline combination. The complete driveline is maintenance-free and offers highly reliable transfer of power, combined with extremely compact transport dimensions thanks to a winning combination of u-joints and finger clutch joints (Fanex 764, 904 and 1124).

ADVANTAGES:
Maintenance-free driveline and strong ProLine gearboxes.
Strong driveline, sturdy u-joints on the inside rotors and flexible HexaLink finger clutch on outside rotors (Fanex 764, 904 and 1124).
Compact transport and storage dimension – storage height is below 3.45m
Strong and sturdy design with closed V-shaped central unit.
Central adjustment for border spreading keeping the crop inside the field.
Largely dimensioned oscillation dampers for excellent running characteristics.
New headland kit for easy turning on headlands.

MODELS

FANEX 554
Working Width 5.50m
Rotors/Tines 4/7
Weight 640kg

FANEX 684
Working Width 6.80m
Rotors/Tines 6/6
Weight 900kg

FANEX 764
Working Width 7.60m
Rotors/Tines 6/7
Weight 990kg

FANEX 904
Working Width 9.00m
Rotors/Tines 8/6
Weight 1260kg

FANEX 1124
Working Width 11.20m
Rotors/Tines 10/6
Weight 1600kg


VICON FANEX 1404C
Fanex 1404C is very easy to use. All operations are run hydraulically, and can be controlled from the tractor cab. The tedders come with a hydraulic adjustment for border tedding, to prevent loss of grass due to ditches or fences. Despite size, both tedders are very easy to run. They are supplied with transport carrier as standard, making it possible to operate the machine in combination with low horsepower tractors.

ADVANTAGES:
Unique transport solution with outer rotors folded onto the carrier frame.
Wide track width of 2m ensures stability.
The carrier frame design limits the tractor size needed.
Hydraulically adjustable border tedding via two or three outer, right hand side rotors.
7 tine arms per rotor for optimal pick-up and distribution of material.
Box type frame composed of two U-sections for extremely solid construction.

MODEL

1404C
Working Width 13.30m
Rotors/Tines 10/7
Weight 2300kg
