Vicon - Disc Rear Mounted Mower Conditioners Wales

VICON EXTRA 732T-732R-736T - REAR MOUNTED MOWER CONDITIONERS

EXTRA 732T-732R-736T are powerful mower conditioners with superb ground tracking, thanks to the new innovative QuattroLink suspension concept. With its´ accurate tracking ability and highly flexible working range, this suspension provides unrivalled cutting performance. Like a race car you want better tracking, ability to go at a faster speed and adjust instantly to changing field conditions when operating your mower conditioner. These are the main benefits you will experience when running the EXTRA 700 series.

ADVANTAGES:

3.18 and 3.50m working width.
New innovative QuattroLink racecar suspension concept.
Flexible suspension – 700mm movements, 400mm upwards and 300mm downwards.
Hydraulic setting of ground pressure.
NonStop BreakAway protection across full working width.
150mm mechanical adjustment of overlap.
Minimum 500mm ground clearance during headland turns.
Dual adjustment of conditioner hood - both front and rear end can be adjusted.
Integrated parking feet for vertical storage.
Vertical Transport Solution.
Counter-rotating triangular discs

MODELS

EXTRA 732T
Working Width 3.18m
Number of Discs 8 triangular discs
Conditioner SemiSwing Steel Tines

EXTRA 732R
Working Width 3.18m
Number of Discs 8 triangular discs
Conditioner Roller Conditioner

EXTRA 736T
Working Width 3.50m
Number of Discs 10 triangular discs
Conditioner SemiSwing Steel Tines

Download Brochure

VICON EXTRA 624T - 628T/R - 632T FARMER - REAR MOUNTED DISC MOWER CONDITIONERS
The Vicon EXTRA 624T, 628T/R and 632T Farmer in working widths of 2.42, 2.84 and 3.18m. They are fitted with the EXTRA cutterbar with slim design for improved cutting performance, and with a choice of either nylon tine or roller conditioning. The mowing units are suspended in the centre of gravity via a large suspension spring. This design provides an even weight distribution across the entire mowing width, as well as a constant, faster and more precise adaptation to ground contours.

ADVANTAGES:

Available with hydraulic spring adjustment.
Centre Mounted Spring Suspension
2.42, 2.84 and 3.18m working width
Nylon Tine or Roller Conditioning
Vertical Transport Solution
600/900 Rpm Conditioner Rotor
Vicon BreakAway System

MODELS

EXTRA 624T
Working Width 2.42m
No. of Discs 6
Conditioner Nylon Tines
Power Requirement 50/70 kW/hp

EXTRA 628T
Working Width 2.84m
No.of Discs 8
Conditioner Nylon Tines
Power Requirement 60/80 kW/hp

EXTRA 628R
Working Width 2.84m
No. of Discs 8
Conditioner Chevron Rollers
Power Requirement 60/80 kW/hp

EXTRA 632T
Working Width 3.18m
No. of Discs 8
Conditioner Nylon Tines
Power Requirement 70/90 kW/hp

Download Brochure

VICON EXTRA 632T PRO - REAR MOUNTED DISC MOWER CONDITIONER
The pulled suspension of the new EXTRA 632T Pro is Vicon know-how transferred to mounted disc mowers - a new standard for ground flotation normally only seen on trailed versions. With its 3.2m working width and hydraulic suspension it is a truly high performance machine that combines perfectly into combination with a front-mounted mower conditioner 3.2m working width.

ADVANTAGES
SemiSwing steel tine conditioning.
Hydraulic centre suspension.
FreeFloat pulled suspension.
Two speed gearbox.
125° vertical transport position.
Fully welded EXTRA cutterbar with triangular discs.

MODEL

EXTRA 632T PRO
Working Width 3.18m
No.of Discs 8 triangular discs
Conditioner SemiSwing
Power Requirement 70/90 kW/hp

VICON EXTRA 736T VARIO- REAR MOUNTED MOWER CONDITIONERS
New line of mounted mower conditioners from Vicon with ground breaking suspension concept. The mowing unit is suspended by four suspension arms that allow the mowing unit to float independently float over the field, and adjust accurately to ground contours. With Vario suspension arm, the mowing unit can be sideshifted 400mm on the go for correct overlap. Ground pressure remains the same. No need to stop and reset ground pressure.

ADVANTAGES:
3.50m working width.
New innovative QuattroLink racecar suspension concept.
Flexible suspension – 700mm movements, 400mm upwards and 300mm downwards.
NonStop BreakAway protection across full working width.
Vario version with hydraulic adjustment of overlap on the go.
Ground pressure remains the same, even when overlap is changed.
Minimum 500mm ground clearance during headland turns.
Integrated parking feet for vertical storage.
Dual adjustment of conditioner hood - both front and rear end can be adjusted
Vertical Transport Solution.
Counter-rotating triangular discs.

MODEL

EXTRA 736T Vario
